Our Products
For Welding & Cutting
home
>
Brands
>
Maxphotonics
>
A1MD30i
A1MD30i
Introducing the future of mobile welding technology.
Whatsapp
Email
HR Laser A1MD30i
Product Description
Product Specification:
Product Model
A1MD30i
Machine Weight
< 29kg
Machine Volume
< 0.08m
Overall Dimensions
577mm x 265mm x 512mm
Torch Weight
0.68kg
Working Mode
Continous / Pulsed “D-Mode”
Laser Wobble
0-4mm
Input Voltage
220VAC
Rated Power
2500W
Operating Temperature
0-40°
Material
Single-side penetration
Stainless Steel
3.0mm
Cabon Steel
3.0mm
Galvanized Steel
3.0mm
Aluminium
2.0mm
Product Packaging Contents:
Handheld Laser (A1MD30i)
1
Soundproof Earplugs
5
Cotton Swab 1
1
Cotton swab 2
1
Dust Mask
2
T10 Screwdriver
1
Safe Return Route
1
Reel
1
Gun Head Rack
1
Armored Cable Rack
1
Eye Protection(OD8+)
1
Hexagon socket head countersunk head screws (M3*8mm)
12
Power Cable (5m)
1
Ground Wire (5m)
1
Silicone Case
1
Wire Feeder Rack
1
Lock Ring Wrench
1
Gas Pipe (Φ6, 5M)
1
Second Vent Quick Plug (Φ6 to Φ10)
1
Wire Feed Nozzle
1
Protective Lens (Φ20*3)
1
Nozzles (1, 3, A, B and flat nozzle)
1
Cutting-Edge D-Mode – Enhanced Penetration Depth with less energy consumption
Achieve Up to 5.0mm in Penetration Depth
Leading the Global Market in Optical and Control Technologies for Enhanced Efficiency, Reduced Energy Use, and Superior Weld Depth
Advanced Aerospace Cooling Technology
Low Power Consumption, Small Footprint, and Exceptional Reliability.
Unmatched Optical Technology: Setting Unprecedented Lightweight Records.
Excellence in Product Design: A Lightweight and Portable Machine Ideal for Mobile Welding. It Features a Light and Flexible Welding Torch, Small Cable Diameter, and Lightweight Construction for Extended Welding Sessions.
Power Precision Control and Calibration Technology for Smooth, Perfect Welding Seams
This technology offers precise control over welding power and automated calibration, with power fluctuation kept under 3%. It ensures a uniformly bright laser beam and ideal linearity, crafting superior weld seams.This technology offers precise control over welding power and automated calibration, with power fluctuation kept under 3%. It ensures a uniformly bright laser beam and ideal linearity, crafting superior weld seams.
Multi-functional Welding Torch with One-Click Control
Features an Integrated Single-Hand Wire Stop Switch, Eliminating the Need to Run Back and Forth, Thereby Improving Production Efficiency.
Smart Wire Feeder: Precision Wire Handling with No Sticking
Benefit from Custom R&D Driven by Laser Control Technology, Offering Strong Power and Exact Control of Wire Feed Speed. It Automatically Retracts upon Laser Pause.
Frequently Purchase Together
Flamax TIG-400P
Flamax ARC-500D
Optimarc CV500P
Weldone PM 2000
OTC D-12000
Weldone TIG-315ACDC
